INA FF3525 Bearing, FF3525 flat cage roller bearings
INA FF3525 bearing is flat cage roller bearings, flat needle roller and cage assemblies.
INA FF3525 bearing cage made of polyamide resin is provided with grooved joint at its both ends so several cages can be jointed together into one unit.
INA FF3525 bearing is INA FF type flat cage roller bearings, This type composed of a cage and needle rollers ensures smooth reciprocating motion of less friction actor by being inserted between two planes in relative position.
We also can provide INA FF‥.ZW type flat needle roller bearing such as FF2025ZW bearing, FF2535ZW bearing, FF3045ZW bearing, FF3555ZW bearing and so on.
BELOW IS THE DETAILED INFORMATION ON INA FF3525 BEARING :
|Bearing Number ||FF3525 Bearing |
|Dw1 (mm) ||3.5 |
|b (mm) ||25 |
|B (mm) || |
|L (mm) ||75 |
|LW (mm) ||17.8 |
|a (mm) ||3.2 |
|Cr (N) ||50000 |
|Cor (N) ||132000 |
|number of rollers ||10 |
|E (mm) ||25.4 |
|H (mm) ||3.2 |
|Weight (KG) ||0.017 |
THE PICTURER OF FF3525 LINEAR NEEDLE ROLLER FLAT CAGE :
