JKOS 050 bearing | JKOS 050 sealed tapered roller bearing used to Agricultural machinery
JKOS 050 Bearing is FAG brand sealed tapered roller bearing used to Agricultural machinery,the main dimensions is 50mmx80mmx22mm. weight is 0.41 KG.
The bore and outside diameter of JKOS 050 integral tapered roller bearing match those of tapered roller bearings of series 320.
JKOS 050 FAG sealed tapered roller bearing can be applied to Agricultural machinery,Fork lift trucks,Cranes and Cable cars.
FEATURES OF JKOS 050 FAG SEALED TAPERED ROLLER BEARING :
JKOS 050 FAG sealed tapered roller bearing are ready-to-fit, easily mounted units.
The single row JK0S050 bearing is sealed on one side and lubricated for life with a high quality grease. The selfretaining bearings are installed in pairs to give a bearing arrangement that is sealed on both sides.
Due to their large support base, the JKOS 050 bearing arrangement can support all load combinations comprising radial forces, axial forces and tilting forces. The support base is significantly larger than in double row cylindrical roller bearings.
JKOS 050 FAG SEALED TAPERED ROLLER BEARING BASIC DIMENSIONS AND SPECIFICATION:
New Model/Bearing number: JKOS 050
Old Model/Old number: JKOS 050
Main demensions: 50 mm × 80 mm × 22 mm
Inside diameter (ID d): 50 mm
Outside diameter (OD D): 80 mm
Thickness/width (T/B/H): 22 mm
Basic dynamic load rating (Cr): 64 kN
Basic static load rating (Cor): 93 kN
Reference speed (Grease rpm): 3700 r/min
Weight, Mass (M): 0.41 kg
Category: Tapered Roller Bearings
