SKF 623 2RS1 Miniature Deep Groove Ball Bearing 3x10x4 Mm

SKF 623 2RS1 Miniature Deep Groove Ball Bearing 3x10x4 Mm, find complete details about SKF 623 2RS1 Miniature Deep Groove Ball Bearing 3x10x4 Mm, SKF Bearing 623, 623 2rs bearing, 623 2rs ball bearing skf - hojebearings.com
Size:
Availability:
Quantity:
  • 623 2rs
  • skf

SKF 623 2RS1 Miniature Deep Groove Ball Bearing 3x10x4 Mm

Bearing Number623-2RS
BrandSKF
TypeMiniature ball bearings
Bore Size d3.000 mm
FeaturesContact Seals
Weight0.0016 Kg
Outside Diameter D10.000 mm
Outside Ring Width B4.000 mm
Radius Rs min0.150 mm
Cr - Dynamic Load Rating0.63 kN
C0r - Static Load Rating0.22 kN
Grease Limiting Speed66000 rpm
Oil Limiting Speed78000 rpm


The Suffix Of Deep Groove Ball Bearings:


RS, 2RS, 2RSH, 2RS1, RSR, 2RSR, E, EE, LLU, LLB, DU, DDU

All these suffixes mean "with 1 or 2 rubber seals".

SKF Brand Ball Bearings Suffix with RS, 2RS, 2RSH, 2RS1.

FAG Brand Ball Bearings Suffix with RSR, 2RSR.

SNR Brand Ball Bearings Suffix With E, EE.

NTN Brand Ball Bearings Suffix With LLU, LLB.

NSK Brand Ball Bearings Suffix With DU, DDU.


C3, C4 :

Means "increased internal game". Often referred to as high speed, this means that the bearing is designed for high rotational speeds and moderately high temperatures.


ZZ, 2Z, ZR, Z:

These suffixes mean "with 1 or 2 Metal shield" for dust proofing.


TN9, TVH, TVP, G15 :

These suffixes indicate that the cage (part of the bearing that keeps the balls at a distance from each other) is made of polymer material. In general, made of fiberglass-reinforced polyamide.


ABEC(1,3,5,7,9) (P0, P6, P5, P4, P2):

The ABEC standard is used to classify bearings by their machining tolerance. This standard is regularly called into question because it does not include certain important technologies to guarantee good functioning, as well as for efficiency as for the lifetime of a bearing.


BHT / VT

This suffix indicates that the bearing is designed for very high operating temperatures. In general, is indicated the temperature following this suffix.
