CF16UUR
IKO
BRAND:IKO
WEIGHT:0,209 KG
SECTIONCAM FOLLOWER
INNER DIAMETER:16,0 MM
OUTER DIAMETER:35,0 MM
WIDTH:18,0 MM
PRODUCT REFCF16-BUUR-IKO
Cam Followers are studded bearings with needle bearings/Rollers inside a thick outer ring. They are available in caged, full complement needles, and Full complement rollers variations and have either a Crowned or Cylindrical outer diameter. They can support high radial and axial loads arising from misalignment and skewed running and are suitable for cam drives, slideways, conveying equipment, etc. The bearings are available in several designs and with or without an eccentric.
Boundary Dimensions in mm | Mounting Dimension f Min. mm | Max Tightening torque | Basic Dynamic Load | Basic Static Load | |||||||||||||
| D | C | d1 | G | G1 | B | B1 | B2 | B3 | C1 | g1 | g2 | H | rs min | ||||
| 35 | 18 | 16 | M16X1.5 | 17 | 19.6max | 52.1max | 32.5 | 8 | 0.8 | 6 | 3 | 6 | 0.6 | 26 | 58.5 | 12000 | 18300 |
BRAND:IKO
WEIGHT:0,209 KG
SECTIONCAM FOLLOWER
INNER DIAMETER:16,0 MM
OUTER DIAMETER:35,0 MM
WIDTH:18,0 MM
PRODUCT REFCF16-BUUR-IKO
Cam Followers are studded bearings with needle bearings/Rollers inside a thick outer ring. They are available in caged, full complement needles, and Full complement rollers variations and have either a Crowned or Cylindrical outer diameter. They can support high radial and axial loads arising from misalignment and skewed running and are suitable for cam drives, slideways, conveying equipment, etc. The bearings are available in several designs and with or without an eccentric.
Boundary Dimensions in mm | Mounting Dimension f Min. mm | Max Tightening torque | Basic Dynamic Load | Basic Static Load | |||||||||||||
| D | C | d1 | G | G1 | B | B1 | B2 | B3 | C1 | g1 | g2 | H | rs min | ||||
| 35 | 18 | 16 | M16X1.5 | 17 | 19.6max | 52.1max | 32.5 | 8 | 0.8 | 6 | 3 | 6 | 0.6 | 26 | 58.5 | 12000 | 18300 |
