PHSA6
IKO
| Identification number | PHSA6 |
|---|---|
| Type | Lubrication type PILLOBALL Rod ends |
| Mass | 25 g |
| d | 6 mm |
| Thread G | M6X1 |
| d2 | 19.5 mm |
| C1 | 6.75 mm |
| B | 9 mm |
| d1 | 9 mm |
| l4 | 39.7 mm |
| h1 | 30 mm |
| l3 | 16 mm |
| l5 | 5 mm |
| W | 11 mm |
| d3 | 10 mm |
| dL | 13 mm |
| r1s min | 0.2 mm |
| Ball dia. | 12.7 mm |
| Dynamic load capacity | 6.76 kN |
Packing , Payment , Delievry and Stock
| Packaging | |
| 1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet | |
| 2)Industrial Bearings packaging | a)plastic tube + carton + pallet |
| b). plastic bag +kraft paper + carton + pallet | |
| 3)According to the requirement of customers' | |
| Payment | |
| 1) T/T:30% deposit, 70% should be paid before shipment. | |
| 2) L/C at sight. (high bank charge, not suggest, but acceptable ) | |
| 3) 100% Western Union in advance. (especially for air shipment or small amount) | |
| Delivery | |
| 1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient ) | |
| 2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive ) | |
| 3) More than 200 KGS, we will send by sea. ( Cheapest, but long time ) | |
| Stock | |
| 1)Availability and supply capacity on a certain basis | |
