23036CDKE4
NSK
This 23036CDKE4 bearing is a Spherical Roller Bearing with a guide ring centred on a flangeless inner ring, two stamped steel cages, a 1:12 tapered bore, an annular groove in the outer ring with three lubrication holes and a normal radial internal clearance. The bearing's dimensions are 180x280x74.
| 230 | 36 | CD | K | E4 | |
|---|---|---|---|---|---|
| Very Light | 180mm - Bore Size | Two Piece Steel Cage Guide Ring | 1:12 Tapered Bore | Groove & Holes, Outer | Normal Internal Clearance |
| BRAND |  |
| SKU | 23036CDKE4-NSK |
| AVAILABILITY | IN STOCK |
| WEIGHT | 17 KG |
| INSIDE DIAMETER (MM) | 180MM |
| OUTSIDE DIAMETER (MM) | 280MM |
| WIDTH (MM) | 74MM |
| CAGE TYPE | STEEL |
| SEALS OR SHIELDS | OPEN TYPE |
| CLEARANCE | STANDARD |
| DYNAMIC LOAD RATING (KN) | 750 |
| STATIC LOAD RATING (KN) | 1270 |
| GREASE LIMITING SPEED (R/MIN) | 1200 |
| OIL LIMITING SPEED (R/MIN) | 1400 |
Packing , Payment , Delievry and Stock
| Packaging | |
| 1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet | |
| 2)Industrial Bearings packaging | a)plastic tube + carton + pallet |
| b). plastic bag +kraft paper + carton + pallet | |
| 3)According to the requirement of customers' | |
| Payment | |
| 1) T/T:30% deposit, 70% should be paid before shipment. | |
| 2) L/C at sight. (high bank charge, not suggest, but acceptable ) | |
| 3) 100% Western Union in advance. (especially for air shipment or small amount) | |
| Delivery | |
| 1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient ) | |
| 2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive ) | |
| 3) More than 200 KGS, we will send by sea. ( Cheapest, but long time ) | |
| Stock | |
| 1)Availability and supply capacity on a certain basis | |
