29322 E
NSK
Accommodates heavy combined load at high speeds
Unaffected by misalignment
Self-aligning
Separable design
| d | 110 mm | Bore diameter |
|---|---|---|
| D | 190 mm | Outside diameter |
| H | 48 mm | Nominal Height |
| d1 | ≈171 mm | Outside diameter of shaft washer end side face |
| D1 | ≈140 mm | Shoulder diameter outer ring |
| B | 30.3 mm | Width shaft washer or length of shaft washer bore diameter that fits on shaft (bearings with a stamped steel cage) |
| B1 | 41.7 mm | Height shaft washer + cage |
| C | 24.8 mm | Height housing washer |
| s | 63.8 mm | Distance from shaft washer end side face to pressure point |
| r1,2 | min.2 mm | Chamfer dimension shaft washer |
| da | min.145 mm | Abutment diameter shaft |
|---|---|---|
| db1 | max.117 mm | Abutment diameter spacer ring (E design bearings) |
| db2 | max.117 mm | Abutment diameter spacer ring (E design bearings) |
| Da | max.164 mm | Abutment diameter housing |
| ra | max.2 mm | Fillet radius |
| Basic dynamic load rating | C | 610 kN |
|---|---|---|
| Basic static load rating | C0 | 1 730 kN |
| Fatigue load limit | Pu | 204 kN |
| Reference speed | 1 900 r/min | |
| Limiting speed | 3 200 r/min | |
| Minimum axial load factor | A | 0.28 |
| Mass bearing | 5.3 kg |
Packing , Payment , Delievry and Stock
| Packaging | |
| 1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet | |
| 2)Industrial Bearings packaging | a)plastic tube + carton + pallet |
| b). plastic bag +kraft paper + carton + pallet | |
| 3)According to the requirement of customers' | |
| Payment | |
| 1) T/T:30% deposit, 70% should be paid before shipment. | |
| 2) L/C at sight. (high bank charge, not suggest, but acceptable ) | |
| 3) 100% Western Union in advance. (especially for air shipment or small amount) | |
| Delivery | |
| 1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient ) | |
| 2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive ) | |
| 3) More than 200 KGS, we will send by sea. ( Cheapest, but long time ) | |
| Stock | |
| 1)Availability and supply capacity on a certain basis | |
Accommodates heavy combined load at high speeds
Unaffected by misalignment
Self-aligning
Separable design
| d | 110 mm | Bore diameter |
|---|---|---|
| D | 190 mm | Outside diameter |
| H | 48 mm | Nominal Height |
| d1 | ≈171 mm | Outside diameter of shaft washer end side face |
| D1 | ≈140 mm | Shoulder diameter outer ring |
| B | 30.3 mm | Width shaft washer or length of shaft washer bore diameter that fits on shaft (bearings with a stamped steel cage) |
| B1 | 41.7 mm | Height shaft washer + cage |
| C | 24.8 mm | Height housing washer |
| s | 63.8 mm | Distance from shaft washer end side face to pressure point |
| r1,2 | min.2 mm | Chamfer dimension shaft washer |
| da | min.145 mm | Abutment diameter shaft |
|---|---|---|
| db1 | max.117 mm | Abutment diameter spacer ring (E design bearings) |
| db2 | max.117 mm | Abutment diameter spacer ring (E design bearings) |
| Da | max.164 mm | Abutment diameter housing |
| ra | max.2 mm | Fillet radius |
| Basic dynamic load rating | C | 610 kN |
|---|---|---|
| Basic static load rating | C0 | 1 730 kN |
| Fatigue load limit | Pu | 204 kN |
| Reference speed | 1 900 r/min | |
| Limiting speed | 3 200 r/min | |
| Minimum axial load factor | A | 0.28 |
| Mass bearing | 5.3 kg |
Packing , Payment , Delievry and Stock
| Packaging | |
| 1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet | |
| 2)Industrial Bearings packaging | a)plastic tube + carton + pallet |
| b). plastic bag +kraft paper + carton + pallet | |
| 3)According to the requirement of customers' | |
| Payment | |
| 1) T/T:30% deposit, 70% should be paid before shipment. | |
| 2) L/C at sight. (high bank charge, not suggest, but acceptable ) | |
| 3) 100% Western Union in advance. (especially for air shipment or small amount) | |
| Delivery | |
| 1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient ) | |
| 2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive ) | |
| 3) More than 200 KGS, we will send by sea. ( Cheapest, but long time ) | |
| Stock | |
| 1)Availability and supply capacity on a certain basis | |
