AXK 1730+2AS
SKF
| d | 17 mm | Bore diameter |
| D | 30 mm | Outside diameter |
| Dw | 2 mm | Diameter roller |
| Ea | min.19 mm | Raceway diameter (min.) roller and cage thrust assembly |
| Eb | max.29 mm | Raceway diameter (max.) roller and cage thrust assembly |
| Basic dynamic load rating | C | 11 kN |
| Basic static load rating | C0 | 40.5 kN |
| Fatigue load limit | Pu | 4.75 kN |
| Reference speed | 4 500 r/min | |
| Limiting speed | 9 500 r/min |
| Mass roller and cage thrust assembly | 0.0037 kg |
Packing , Payment , Delievry and Stock
| Packaging | |
| 1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet | |
| 2)Industrial Bearings packaging | a)plastic tube + carton + pallet |
| b). plastic bag +kraft paper + carton + pallet | |
| 3)According to the requirement of customers' | |
| Payment | |
| 1) T/T:30% deposit, 70% should be paid before shipment. | |
| 2) L/C at sight. (high bank charge, not suggest, but acceptable ) | |
| 3) 100% Western Union in advance. (especially for air shipment or small amount) | |
| Delivery | |
| 1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient ) | |
| 2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive ) | |
| 3) More than 200 KGS, we will send by sea. ( Cheapest, but long time ) | |
| Stock | |
| 1)Availability and supply capacity on a certain basis | |
