29412 EM
Thrust Spherical Roller Bearings 29412 EM, (60*130*42 mm), 60 mm d (Bore: diameter of the inner ring), 130 mm D (Outside: diameter of the outer cylindrical surface of the outer ring), 42 mm B (Width: nominal width of the bearing),
| d | 60 mm | Bore diameter |
|---|---|---|
| D | 130 mm | Outside diameter |
| H | 42 mm | Nominal Height |
| d1 | ≈ 112 mm | Outside diameter of shaft washer end side face |
| D1 | ≈ 85.5 mm | Shoulder diameter outer ring |
| B | 27 mm | Width shaft washer or length of shaft washer bore diameter that fits on shaft (bearings with a stamped steel cage) |
| B1 | 36.7 mm | Height shaft washer + cage |
| C | 21 mm | Height housing washer |
| s | 38 mm | Distance from shaft washer end side face to pressure point |
| r1,2 | min. 1.5 mm | Chamfer dimension shaft washer |
| da | min. 90 mm | Abutment diameter shaft |
|---|---|---|
| db1 | max. 67 mm | Abutment diameter spacer ring (E design bearings) |
| db2 | max. 67 mm | Abutment diameter spacer ring (E design bearings) |
| Da | max. 107 mm | Abutment diameter housing |
| ra | max. 1.5 mm | Fillet radius |
| Basic dynamic load rating | C | 390 kN |
|---|---|---|
| Basic static load rating | C0 | 915 kN |
| Fatigue load limit | Pu | 114 kN |
| Reference speed | 2 800 r/min | |
| Limiting speed | 5 000 r/min | |
| Minimum axial load factor | A | 0.08 |
| Mass bearing | 2.6 kg |
Packing , Payment , Delievry and Stock
| Packaging | |
| 1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet | |
| 2)Industrial Bearings packaging | a)plastic tube + carton + pallet |
| b). plastic bag +kraft paper + carton + pallet | |
| 3)According to the requirement of customers' | |
| Payment | |
| 1) T/T:30% deposit, 70% should be paid before shipment. | |
| 2) L/C at sight. (high bank charge, not suggest, but acceptable ) | |
| 3) 100% Western Union in advance. (especially for air shipment or small amount) | |
| Delivery | |
| 1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient ) | |
| 2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive ) | |
| 3) More than 200 KGS, we will send by sea. ( Cheapest, but long time ) | |
| Stock | |
| 1)Availability and supply capacity on a certain basis | |
