Name: PASE60-XL-N INA Housing and Bearing (assembly) GRAE60-XL-NPPB
Brand: INA
Rating: 5.0 (64 reviews)

+86-635-2682555 | allen@hojebearing.com

H	69.9 mm	Distance shaft axis
A	60 mm	Width (base)
A1	42 mm	Width (head)
H1	25 mm	Heigth (base)
B1	53.1 mm	Locking collar total width
S1	39.6 mm	Distance of raceway to locking collar
Q	M6	Connection thread lubrication

d	60 mm	Inner diameter bearing
d	2.36 in	Inner diameter bearing
d	2 3/8 in	Inner diameter bearing
D	110 mm	Outer diameter bearing
D	4.33 in	Outer diameter bearing
H	140 mm	Housing height
H	5.51 in	Housing height
L	240 mm	Housing length
L	9.45 in	Housing length
B	60 mm	Housing width
B	2.36 in	Housing width
h	69.9 mm	Height bearing seat
h	2.75 in	Height bearing seat
m	7.48 in	distance between mounting bolt centerlines (length)
Cr	56,000 N	Basic dynamic load rating
Cr	12,589.93 lbf	Basic dynamic load rating
C0r	8,093.53 lbf	Basic static load rating
C0r	36,000 N	Basic static load rating
	PASE60-XL-N-FA125	Housing in kit
	GRAE60-XL-NPP-B-FA125	Bearing in kit

PASE60-XL-N INA Housing and Bearing (assembly) GRAE60-XL-NPPB

Related Products

Tmin	-20 °C	Operating temperature min.
Tmax	120 °C	Operating temperature max.

Packaging
1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet
2)Industrial Bearings packaging	a)plastic tube + carton + pallet
	b). plastic bag +kraft paper + carton + pallet
3)According to the requirement of customers'
Payment
1) T/T:30% deposit, 70% should be paid before shipment.
2) L/C at sight. (high bank charge, not suggested, but acceptable )
3) 100% Western Union in advance. (especially for air shipment or small amounts)
Delivery
1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
Stock
1)Availability and supply capacity on a certain basis
